Supermicro 2029P-TXRT SuperServer SYS-2029P-TXRT

Optimised for Industrial Server Solutions, Networking Telephony and Surveillance DCR. 2x 10GBase-T ports via Intel X550-AT2 Integrated IPMI 2.0 with KVM and Dedicated LAN. 2x PCI-E 3.0 x16 slots, 2x PCI-E 3.0 x16 slots, 4x PCI-E 3.0 x8 slots. Redundant Power Option.

  • Industrial Server Solutions
  • Networking Telephony
  • Surveillance DCR
  • GPU Pass-through VM server
  • Flash Array Server
  • Head-node Controller
  • Dual Socket P (LGA 3647) support 2nd Gen. Intel Xeon Scalable processors (Cascade Lake/Skylake)‡
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel Optane™ DCPMM
  • 2 PCI-E 3.0 x16 slots, 2 PCI-E 3.0 x16 slots (or 4 PCI-E 3.0 x8), 4 PCI-E 3.0 x8 slots, 1 PCI-E 3.0 x4 (in x8 slot)
  • 16 Hot-swap 2.5" SAS/SATA drive bays, 1 slim DVD-ROM drive bay
  • 2x 10GBase-T ports via Intel X550-AT2
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
  • 1 PCI-E 3.0 x4 M.2 2280 slot from PCH
  • 4 middle fans
  • 1000W Redundant Power Supplies Titanium Level (96%)



Loading Configurator...

Prices for products are subject to change without notice and Prices do not include shipping and/or handling charges or applicable taxes.

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon SP processor range, delivering massive improvements in every metric over the previous generation of Xeon E7 and E5 processors.

Up to 12 DIMMs per CPU

This system is capable of supporting up to 12 DIMMS per CPU. That’s a significant advancement on the previous limit, which was 9 DIMMS per CPU.

Security Without Compromise

Intel Xeon Scalable Processor based servers feature security without compromise, incorporating a number of technologies that aid in safeguarding your system.

Accelerated Applications

Applications can be accelerated via the addition of Intel QAT (Quick Assist Technology) to a software-defined infrastructure environment.

Configure With Dual Processors

Featuring dual processors, this system enjoys boosts to its performance for multi-threaded programs, allowing for smooth performance for the most demanding CPU intensive applications.

Configure With Up to 4TB Of RAM

Equipable with up to an gigantic 4TB of RAM, which allows for fast and efficient multi-tasking for the most RAM intensive applications.

Head-Node Controller

Optimised for the role head-node controller, this server can control storage and is a robust and reliable option. It is also compatible with all major storage operating systems.

Configure With Hot-Swap Drives

The Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 2.5" Drives

The Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Intel X550-AT2 Dual Port 10GBase-T

Featuring an Intel X550-AT2 Dual Port 10GBase-T network adapter which delivers high performance. This server is fully free from vendor lock-in and features wide ranging hardware and software compatibility.


A 2U Supermicro SuperServer based on 2x Intel Intel Xeon Scalable Processors range of processors, the Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT is configurable with up to 16x Hot-Swap Drives drive bays, and designed for optimal performance with 16x 3200Mhz DDR4 memory sockets .

The Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT supports the Intel Intel Xeon Scalable Processors 2nd Generation family in a high-density 2U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT boasts 11 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-2029P-TXRT SuperServer | 2029P-TXRT Specs
  • Brand: Supermicro
  • U Size: 2U
  • Processor Family: Intel Xeon Scalable Processors
  • Range: Head-Node Controller Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 2TB
